98ZJ311······1

總說明(一)······4

總說明(二)-(四)······5

防水混凝土說明(一)-(三)······8

防水混凝土施工縫防水詳圖······11

防水混凝土后澆帶防水詳圖······12

涂膜防水說明(一),(二)······13

防水混凝土及磚砌地下室涂膜防水做法······15

條形基礎磚砌地下室涂膜防水做法······16

采光窗井涂膜防水做法······17

涂膜防水預埋式橡膠止水帶變形縫詳圖······18

涂膜防水可卸式橡膠和鋼板止水帶變形縫詳圖(一),(二)······19

涂膜防水固定式穿墻管詳圖······21

涂膜防水套管式穿墻管詳圖······22

卷材防水說明······23

防水混凝土和磚砌地下室卷材防水做法······24

條形基礎磚砌地下室卷材防水做法······25

防水混凝土及卷材,涂料混合防水做法及采光窗井卷材防水做法······26

采光窗井卷材防水做法······27

卷材保護墻平面布置,變形縫大樣······28

卷材封口,外墻壓頂及頂板卷材防水做法節點大樣······29

卷材防水預埋式橡膠止水帶變形縫詳圖······30

卷材防水可卸式橡膠和鋼板止水帶變形縫詳圖(一),(二)······31

卷材防水穿墻管詳圖······33

套管式穿墻管詳圖······34

可卸式止水帶變形縫詳圖······35

變形縫鋼蓋板,止血帶······36

防潮說明······37

防潮做法······38

采光窗井防潮做法······39

地溝與外墻連接處防潮做法······40

變形縫防潮詳圖······41

降排水防水說明······42

降排水做法(一)-(三)······43

盲溝詳圖······46

檢查井詳圖······47
